Original: $3,550.00
-70%$3,550.00
$1,065.00The Story
AMGO MRL09 Mid-rise Scissors Lift
The MRL09 showcase an innovative two-stage runway design, creating a discreet low-profile entrance for a wide range of vehicles to enter from either side, accommodating low clearance cars. Ease to use, barely maintenance required, it’s the ideal mid-rise quick service lift.
Product Features
- 9,000lbs(4000kg) capacity.
- Mid rise scissors lift, 24V Safety voltage control.
- Dual hydraulic synchronization & hydraulic locking system;
- The lifting scissors are made of thickened steel which is more strong;
- Adjustable lift platform length, applicable to vehicles with different wheelbases;
- Two-stage drive in ramps, suitable for lifting ultra-low chassis vehicles;
- Flexible structure design, users can choose either flush mount or surface mount installation;
- Standard ETL certificated power unit;
AMGO global 5-3-2 warranty policy:
- Five-year Warranty on Steel Components,
- Three-year Warranty on Hydraulic Parts,
- Two years on Electrical Components.
Product Specifications
| Model | MRL09 |
|---|---|
| Lifting Capacity | 9,000 lbs |
| Lifting Time | 29s |
| A: Max. Lifting Height | 47 1/4" |
| B: Minimum Height | 5 1/2" |
| C: First Stage Ramp Height | 2 3/4" |
| D: Overall Length (Inc. ramps) | 157 1/16" |
| E: Overall Width | 76 3/4" |
| F: Width Between Runways | 29 1/2" |
| G: Runway Length | 61 3/8" - 77 1/8" |
| Gross Weight | 1,788 lbs |
| Motor | 2.0HP |
Pick Up and Delivery
Our Pick Up locations for AMGO are located in Manning, SC / Dallas, TX / Temecula, CA.
Call, text, or chat with us if you have questions. 866-774-7743
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
AMGO MRL09 Mid-rise Scissors Lift
The MRL09 showcase an innovative two-stage runway design, creating a discreet low-profile entrance for a wide range of vehicles to enter from either side, accommodating low clearance cars. Ease to use, barely maintenance required, it’s the ideal mid-rise quick service lift.
Product Features
- 9,000lbs(4000kg) capacity.
- Mid rise scissors lift, 24V Safety voltage control.
- Dual hydraulic synchronization & hydraulic locking system;
- The lifting scissors are made of thickened steel which is more strong;
- Adjustable lift platform length, applicable to vehicles with different wheelbases;
- Two-stage drive in ramps, suitable for lifting ultra-low chassis vehicles;
- Flexible structure design, users can choose either flush mount or surface mount installation;
- Standard ETL certificated power unit;
AMGO global 5-3-2 warranty policy:
- Five-year Warranty on Steel Components,
- Three-year Warranty on Hydraulic Parts,
- Two years on Electrical Components.
Product Specifications
| Model | MRL09 |
|---|---|
| Lifting Capacity | 9,000 lbs |
| Lifting Time | 29s |
| A: Max. Lifting Height | 47 1/4" |
| B: Minimum Height | 5 1/2" |
| C: First Stage Ramp Height | 2 3/4" |
| D: Overall Length (Inc. ramps) | 157 1/16" |
| E: Overall Width | 76 3/4" |
| F: Width Between Runways | 29 1/2" |
| G: Runway Length | 61 3/8" - 77 1/8" |
| Gross Weight | 1,788 lbs |
| Motor | 2.0HP |
Pick Up and Delivery
Our Pick Up locations for AMGO are located in Manning, SC / Dallas, TX / Temecula, CA.
Call, text, or chat with us if you have questions. 866-774-7743
